TECHNICAL SPECIFICATIONS





    Capacity in Tons 5 Ton  10 Ton   20 Ton   30 Ton   50 Ton   75 Ton   100 Ton   150 Ton   200 Ton
  Bed Size

10" x 17"

254 x430

13" x 19"

330 x 482

141/2" x 22"

368 x560

16" x 26"

405 x 660

20" x 30"

508 x 762

22" x 32"

560 x 812

27" x 37"

685 x 940

29" x 40"

735 x 1015

32" x 48"

812 x 1220

  Bed to Ram

9" / 230

10" / 254 11" / 28 12" / 305 13" / 330 14" / 355 17" / 430 19" / 480 20" / 508
  Bed Bor

31/2" / 90

4" / 100 41/2" / 115 5" / 127 6" / 150 7" / 175 8" / 200 9" / 225 101/2" / 268
  Gear Dia 16" / 405 18" / 457 22" / 560 24" / 610 26" / 660 30" / 762 34" / 865 38" / 965 42" / 1065
  Fly Wheel Dia 19" / 482 21" / 533 25" / 635 28" / 710 32" / 812 36" / 915 39" / 990 44" / 1117 48" / 1220
  Crank Shaft Dia 23/4" / 70 3" / 75 31/2" / 90 4" / 100 43/4" / 118 51/2" / 140 61/2" / 165 71/2" / 190 81/4" / 210
  Back Shaft Dia 21/4" /55 21/4" /55 21/2" / 65 23/4 / 770 3 1/8" / 80 31/2" / 90 4" / 100 43/4" / 1 / 8 5" / 125
  Stroke 2" / 50 21/4" / 55 21/2" / 65 3" / 75 31/2" / 90 4" / 100 41/2" / 115 5" / 125 6" / 150
  Hole in Ram Die Clamping 1725mm 9/8/28mm 11/4" / 32mm 13 / 8" / 35mm 11/2" / 38mm 13/4" / 45mm 2" / 50mm 21/4" / 55mm 2 3/8" / 60mm
  No. of Stokes 80 75 65 60 60 55 50 45 40
  Pulley size 5" 5" 6" 6" 7" 7" 7" 7" 7"
  Total Height 60" 28" 71 76 82 87 94" 102" 112"
  Motor Required 1 H.P. 64 2 H.P. 3 H.P. 5 H.P. 5 H.P. 71/2 H.P. 10 H.P. 15 H.P.
  Floor to Top of Bed 27" 1 H.P. 29" 30" 30" 30" 30" 30" 30"
