Standard Features & Accessories

• Complete With Electricals ie., Saw drive Electric Motor, Coolant pump, On off Contacter with Push Buttons
• V-belt Pulleys with V-belt
• Job Stopper
• Oil Field Gearbox & Hydraulic Cylinder
• Friction Type Chip Removal Wire Brush

Specifications

Cutting Capacity	Unit	LK-1 CS	LK-1 HS	LK-251 HS	LK-2 HS	LK-3 HS	LK-4 HS	LK-5 HS
Round	mm	175	175	250	300	350	400	450
Square	mm	150 x 150	150 x 150	200 x 200	250 x 250	300 x 300	350 x 350	400 x 400
Blade Dimensions	mm	2540 x 20 x 0.9	3000 x 27 x 0.9	3200 x 27 x 0.9	3760 x 27 x 0.9	4100 x 34 x 1.1	4420 x 34 x 1.1	4570 x 34 x 1.1
Power Req.	440 V AC, 50 Hz	0.5 HP	1.0 HP	1.5 HP	2.0 HP	2.0 HP	2.0 HP	2.0 HP
Dimensions (L x W x H )	Mtr.	1.5 x 0.6 x 0.9	1.7 x 0.6 x 0.9	1.8 x 0.7 x 1	2.4 x 0.9 x 1.1	2.6 x 0.9 x 1.1	2.7 x 0.9 x 1.2	2.8 x 0.9 x 1.2
Net Weight	Kg.	270	320	375	760	820	900	450

MACHINE OPERATION :- (MANUALLY OPERATAED)

Job is placed on machine vice and its length is set as per the requirement. Vice is clamp manually by its handle and Saw drive is mande on,,Saw Arm is moved down upto job then as per gravity / cutting pressure blade cutts the job, After cutting operation completes the machine automatically stops in lower position.
