Salient Accessories

• Tool box
• Balancing stand and balancing arbor
• Star type nut
• Flange wrench
• Screw driver
• Balance screw
• open-end wrench
• Innerhexagon spanner
• Wheel dresser
• Setting plate
• wheel flange
• Diamond dresser
• Permanent Magnetic chuck
• Coolant system
• Working lamp

Optional Accessories:

Handwheel, Flange, Retainer with Steel balls (two units), Synchronous bell, Demagnetizer, Digital readout system, Precision Vice, Tiltable permanent chuck, Dust collector, Electromagnetic chuck

Technical Specifications SPECIFICATIONS

Technical Parameters	Unit	ASG 480	ASG 550	ASG 600	ASG 750	ASG 1000
Max. workpiece to be Ground (LxWxH)	mm	520x220x490	600x250x490	630x310x390	780x320	1100x410
Max. Grinding Length	mm	530	600	630	780	1100
Max. Grinding Width	mm	220	250	320	330	410
Table Size (LxW)	mm	480x220	550x260	600x300	750x300	1000x400
Wheel Size (dia.xwidthxbore)	mm	200x16x31.75	200x16x31.75	250x25.4x76.2	250x25.4x76.2	350x40x127
Machine Size (LxWxH)	mm	1680x1140x1800	1680x1140x11800	1960x1480x1850	1960x1480x1850	3150x1673x2045
Gross. Net	T	0.85 0.75	1.0 .09	1.43 1.3	1.43,1.3	3.8,3.5
