Salient Features

  •  Closed Grain Cast iron Coloumn, arm, work head & gears.
  •  Parts Finished on imported grinding machine all moving parts Finished to close tolerance.
  •  Parts Properly balanced prior assemly.
  •  Main Spindle & pinion mode on DM forged steel.
  •  Alloy steel spindle rom.

Standard Accessories

• Motor pulley in all machines.
• Complete Electrical Suitable for 415 Volts 50Hz 3 phase AC Supply (Electrical Panel Board & Switched) in Model R40BA & P40AA

Extra Accessories

  •  Electrical Motors
  •  Drill Chuck & Arbor
  •  Tapping Control panel board
  •  Vee Belts
  •  Work table
  •  Coolant pump with coolant tank
  •  Keyless drill chuck & arbor
  •  Extra long Column

Technical Specifications

	DESCRIPTION	AR40
	Drilling CapacityDrilling Capacity	40
	Spindle taper	MT-4
	Spindle travel	250
	Spindle speeds (rpm x step)	88-2600x8
	Spindle autofeed ranges (mm/rev.)	Flne feed
	Max/min dist.spindle nose to base	850 / 250
	Diameter of colum	170
	Work table	300x300x385
	Drill-head / elevating motor	1.5hp/0.5hp
	Built-in coolant tank	yes
